ENLBP2008060PT/SP

Assembly units	Dimensions (mm)			Door type	With mounting plate
Assembly units	Height	Width	Depth	Door type	With mounting plate
40 U	2000	800	600	Single transparent	No

Plan pdf pdf

Data sheet pdf

Technical data

Technical data
Protection degree	IP55
NEMA degree of protection	1, 12
Resistance to impact	IK09
Certificates and regulations
Directive	2014/35/EU
Norms	UNE-EN 62208,UNE-EN 61439-1

Accessories

Image	Reference	Description
Lifting eyebolts (1)
	48115	M12 lifting eyebolts
(1)
	48460	5-mm double-bit key
Insulation joint (1)
	48480	Adhesive insulation joint
Total plain mounting plates (1)
	PL20080	Total metal plain mounting plate 2000x800
Parcial plain mounting plates (4)
	PLP2080	Partial plain metal mounting plate 200x800
	PLP3080	Partial plain metal mounting plate 300x800
	PLP4080	Partial plain metal mounting plate 400x800
	PLP6080	Partial plain metal mounting plate 600x800
PACK 4: Side panels (1)
	PLA20060	Pack 4: Side panels
Linking plates (1)
	PLC2000	Metal linking plate for ENL2000 cabinet
PACK 5: Opaque doors (1)
	PO20080	Pack 5: Single opaque door
Separation plates (1)
	PLS20060	Metal separation plate 2000x600
Plate reinforcement kit (1)
	KRPL80	Reinforcement kit for plates width 800 mm
Slide way (2)
	48500	Sliding guide joint pack (screws + M8x16 nuts)
	GD800	Guide set 800
Accessory packs for plates (5)
	48471	Total plate assembly support
	48472	Partial plate assembly support
	48473	Total plate central support
	48474	Linking plate assembly support
	48624	Bracket for partial separator plate assembly
Connection packs for combinable cabinets (3)
	48111	Internal connection of combinable cabinets
	48112	Corner connection of combinable cabinets
	48116	Mixed connection pack: 4 pcs. internal connection + 4 pcs. corner connection
Connection and lifting packs (1)
	48114	Linking and lifting brackets for linkable cabinets
Wall-mounting pack (1)
	48113	Wall-mounting brackets
Insulation joint (1)
	48478	Light grey corner finishing joint strip (6 m)
Insulation joint for horizontal profiles (1)
	48479	Insulation joint for horizontal profiles (6 m)
Insulation joint pack (1)
	48636	ENL cabinet joint insulation strip pack
Insulation brush (1)
	48481	Insulation brush (2 m)
Earthquake kit for equipping baying system (1)
	KRS2008060	ENL2008060
Earthquake kit for plates (1)
	KRSPL20080	PL20080
Earthquake plinth (1)
	KRSZCL108060	100x800x600
Trim frame (1)
	MEB20080	Trim frame 2000x800
Modular frame (without partition) (1)
	BTM20080	Modular frame 2000x800
Modular frame (with partition column) (1)
	BTM20080/E200	Modular frame 2000x800 with 200 mm partition column
Covers for modular frame. FIXED MODULAR (4)
	TMF1580	Fixed modular cover 34 mod 150x800
	TMF2080	Fixed modular cover 34 mod 200x800
	TMF3080	Fixed modular cover 2x34 mod 300x800
	TMF4080	Fixed modular cover 2x34 mod 400x800
Covers for modular frame. FIXED PLAIN (7)
	TCF0580	Fixed blind modular cover 50x800
	TCF1080	Fixed blind modular cover 100x800
	TCF1580	Fixed blind modular cover 150x800
	TCF2080	Fixed blind modular cover 200x800
	TCF3080	Fixed blind modular cover 300x800
	TCF4080	Fixed blind modular cover 400x800
	TCF6080	Fixed blind modular cover 600x800
Covers for modular frame. MODULAR HINGED (4)
	TMA1580	Modular hinged cover 33 mod 150x800
	TMA2080	Modular hinged cover 33 mod 200x800
	TMA3080	Modular hinged cover 2x33 mod 300x800
	TMA4080	Modular hinged cover 2x33 mod 400x800
Attachment kit + DIN rail (for modular covers) (1)
	48156	Fixing kit + DIN rail 800 mm
Vertical trunking support kit (1)
	49367	Vertical duct + DIN rail support 800 mm
Horizontal trunking support (1)
	49368	Horizontal duct support
Auxiliary module (2)
	MEX2003060	Auxiliary module 2000x300x600
	MEX2004060	Auxiliary module 2000x400x600
Busbar chamber (2)
	CE308060	Busbar chamber top-bottom
	CE408060	Busbar chamber top-bottom
Panels for busbar chamber. SIDE PANELS (2)
	PLCE3060	Side panel
	PLCE4060	Side panel
Ventilated plinth (corner pieces and front covers) (1)
	ZCLV2080	Ventilated sheet steel plinth 200x800. Corner + front cover
Plinth (corner pieces and front covers) (2)
	ZCL1080	Sheet steel plinth 100x800. Corner pieces and front and rear covers
	ZCL2080	Sheet steel plinth 200x800. Corner pieces and front and rear covers
100+100 plinth (corner pieces and front covers) (1)
	ZCL2T1080	Sheet steel plinth 200x800. Corner pieces and 2 covers 100+100
Side covers for plinth (2)
	TLZCL1080	Side cover for sheet steel plinth 100x800
	TLZCL2080	Side cover for sheet steel plinth 200x800
Mounting profiles. FOR MODULAR FRAME (1)
	PMB600	Profile for modular frame
Mounting profiles. REINFORCED OUTSIDE ASSEMBLY (1)
	PMER800	Reinforced external mounting profile
Mounting profiles. OUTSIDE SIMPLE ASSEMBLY (1)
	PMES600	Simple external mounting profile
Mounting profiles. INTERIOR PARTITION (1)
	PPI600	Interior partition profile
Swing tray (1)
	48776	Swing-out tray for PC
Side canopy for attachable canopy (galvanised steel) (1)
	TEJL60	Side canopy for cabinet depth 600 mm (right + left)
Central canopy connection for attachable canopy (galvanised steel) (1)
	TEJC60	Central union of canopies for cabinet depth 600 mm
Interlocking and actuation systems for doors (1)
	48515	Interlocking and operating system for main cabinet
(1)
	48634	Trim lock + 5-mm double-bit insert
Inserts for lock with handle (6)
	48463	8-mm triangular insert lock + key
	48464	Keyless pressure insert lock
	48465	Security insert lock + code 333 key
	48541	6.5-mm triangular insert lock + key
	48585	Security insert lock + code 405 key
	48588	Security insert lock + code 1242E key
Door retainer (1)
	48466	Door retainer L=230
Door switch with lever (1)
	48462	Door switch with adjustable lever. Screw fixing
Door switch with push button (1)
	48620	Door switch with linear push button. Screw fixing
Transport casters (1)
	48290	Transport wheels 150 kg
Levelling feet (1)
	48300	Leveling feet 270 kg
Ventilated roof (1)
	TVN8060	Ventilated roof 800x600
Roof-elevating items (1)
	48152	Roof spacers
Document pocket (1)
	49387	Metal document pocket 800

Spare parts

Image	Reference	Description
Accessory packs for plates (1)
	48419	Separation plate assembly supports
Inner door (1)
	PIN20080	Inner door 2000x800
Lock with handle (1)
	48633	Lever-handle lock + 5-mm double-bit insert
Hinges and retainers (4)
	48082	Lock retainer
	48626	Standard hinge 120°
	48628	180° Right hinge
	48629	180° Left hinge
