IP55-IP65 Rolled steel floor-standing compact cabinets


OPAQUE SINGLE DOOR WITH PLATE
Reference Dimensions (mm) Door type With mounting plate Image Drawings FT
Height Width Depth pdf dxf 3D edz pdf
BIG1656040PO1650600400Opaca únicaYes
BIG1658040PO1650800400Opaca únicaYes
BIG16510040PO16501000400Opaca únicaYes
BIG1806040PO1800600400Opaca únicaYes
BIG1808040PO1800800400Opaca únicaYes
BIG1808050PO1800800500Opaca únicaYes
BIG18010040PO18001000400Opaca únicaYes
BIG18010050PO18001000500Opaca únicaYes
BIG2006040PO2000600400Opaca únicaYes
BIG2008040PO2000800400Opaca únicaYes
BIG2008050PO2000800500Opaca únicaYes
BIG20010040PO20001000400Opaca únicaYes
BIG20010050PO20001000500Opaca únicaYes
OPAQUE DOUBLE DOOR WITH PLATE
Reference Dimensions (mm) Door type With mounting plate Image Drawings FT
Height Width Depth pdf dxf 3D edz pdf
BIG16510040POD16501000400Opaca dobleYes
BIG16512040POD16501200400Opaca dobleYes
BIG18010040POD18001000400Opaca dobleYes
BIG18010050POD18001000500Opaca dobleYes
BIG18012040POD18001200400Opaca dobleYes
BIG18012050POD18001200500Opaca dobleYes
BIG20010040POD20001000400Opaca dobleYes
BIG20010050POD20001000500Opaca dobleYes
BIG20012040POD20001200400Opaca dobleYes
BIG20012050POD20001200500Opaca dobleYes
BIG20016040POD20001600400Opaca dobleYes
BIG20016050POD20001600500Opaca dobleYes

Range

Standard:
- Opaque door cabinets with mounting plate.
- Single door up to width of 1000 mm.
- Double door as of width of 1000 mm.
- Height: 1650 - 1800 - 2000 mm.
- Width: 600 - 800 - 1000 - 1200 mm.
- Depth: 400 - 500 mm.
To order:
- Special cabinets, dimensions, cut-outs, colours, etc.

Materials

- Cold-rolled steel. - Injected polyurethane sealing gasket.

Finishes

Coated with primer, and hardened polyester grey RAL 7035 paint, embossed, with UV protection.

Supply

- Supplied on pallets, protected with honeycomb cardboard corner pieces and shrink-wrap film. - The plate is supplied assembled. - Key.
