IP66 Rolled steel terminal boxes


WITH CABLE ENTRY
Reference Height (mm) Width (mm) Depth (mm) With mounting plate cover type Image Drawings FT
pdf dxf 3D edz pdf
EXA3015135300150135NoOpaca atornillada
EXA3020135300200135NoOpaca atornillada
EXA3030135300300135NoOpaca atornillada
EXA4020135400200135NoOpaca atornillada
EXA4030135400300135NoOpaca atornillada
EXA4040135400400135NoOpaca atornillada
EXA5020135500200135NoOpaca atornillada
EXA5030135500300135NoOpaca atornillada
EXA6020135600200135NoOpaca atornillada
EXA6030135600300135NoOpaca atornillada
EXA6040135600400135NoOpaca atornillada
EXA8020135800200135NoOpaca atornillada
EXA8040135800400135NoOpaca atornillada
PLAIN SIDES
Reference Height (mm) Width (mm) Depth (mm) With mounting plate cover type Image Drawings FT
pdf dxf 3D edz pdf
ELA1515135150150135NoOpaca atornillada
ELA15159015015090NoOpaca atornillada
ELA2015135200150135NoOpaca atornillada
ELA20159020015090NoOpaca atornillada
ELA2020135200200135NoOpaca atornillada
ELA20209020020090NoOpaca atornillada
ELA3015135300150135NoOpaca atornillada
ELA30159030015090NoOpaca atornillada
ELA3020135300200135NoOpaca atornillada
ELA30209030020090NoOpaca atornillada
ELA3030135300300135NoOpaca atornillada
ELA4020135400200135NoOpaca atornillada
ELA40209040020090NoOpaca atornillada
ELA4030135400300135NoOpaca atornillada
ELA4040135400400135NoOpaca atornillada
ELA5020135500200135NoOpaca atornillada
ELA5030135500300135NoOpaca atornillada
ELA6020135600200135NoOpaca atornillada
ELA6040135600400135NoOpaca atornillada
ELA8020135800200135NoOpaca atornillada

Range

Standard
- Boxes with plain sides and screw-on cover with depths of 90 and 135 mm.
- Boxes with cable-entry and screw-on cover with a depth of 135 mm.
To order
- Special boxes, dimensions, cut-outs, colours, etc.

Materials

- Cold-rolled steel. - Injected polyurethane sealing gasket.

Finishes

Coated with hardened grey RAL 7035 embossed polyester paint, with UV protection.

Supply

Supplied in individual packaging containing the enclosure, cover and the accessory bag.
Accessory bag:
- Screws plus caps for enclosure-cover fixing.
- Side and central brackets (central bracket only for boxes with height of 600 and 800 mm).
- Cable-entry cover plus screws (only included in EXA type references).
- Ø9 mm caps for wall mounting and drainage.
